1. Conveyor belt 2. Drive device (electric roller): composed of motor, hydraulic coupling, reducer, coupling, brake (backstop), etc. 3. Drive roller: It is the main component of transmission power. The diameter of the roller is (cm): 500, 630, 800, 1000. The surface of the roller is: steel smooth surface, herringbone and diamond pattern rubber covering. 4. Redirection roller: It is used to change the running direction of the conveyor belt or increase the angle between the conveyor belt and the drive roller. 5. Roller: It is used to support the conveyor belt and the materials carried on the conveyor belt to ensure the stable operation of the conveyor belt. 6. Tensioning device: It makes the conveyor belt have enough tension, ensures the friction between the conveyor belt and the drive roller, prevents the conveyor belt from slipping, and limits the sag of the conveyor belt between the rollers, so that the conveyor can run normally. 7. Cleaner: It is used to clean the materials adhering to the conveyor belt. There are two types: head cleaner and empty section cleaner. 8. Unloading device, guide chute: The unloading device is used to unload materials at any point in the middle of the conveyor. The belt speed is less than or equal to 2.5m/s, the material size is less than 50mm, and the conveyor adopts a vulcanized joint of the conveyor belt. Guide chute: The materials falling from the funnel are concentrated in the middle of the conveyor belt before reaching the belt speed. The bottom width of the guide chute is 2/3-1/2 of the belt width. 9. Frame: A device that supports rollers and bears the tension of the conveyor belt. 10. Head funnel: A device used for pouring materials and controlling the direction of material flow, and can also play a dust-proof role. 11. Safety protection device: A device that monitors and alarms when a conveyor fails during operation, which can ensure safe production and normal operation of the conveyor system, prevent damage to mechanical components, and protect the safety of operators. At the same time, it is convenient for centralized control and improves the level of automation. There are also anti-deviation switches, anti-slip detection devices, anti-pull rope switches, and anti-longitudinal tearing detectors.
