Screw elevators introduction
Bucket elevators (TD200) series is provided by the manufacturer -Wuxi Changrong Conveying Machinery Company which established in 2001.It is belt type .Such belt type bucket elevator is designed for continuous transportation of bulk materials of volume weight is light.Inclusively such as ceramic powder,paper pulp waste, plastic granules, fruit paste etc. belt bucket elevators are used to lift products from initial up to end point without intermediate loading and unloading .
Wuxi Changrong Vertical belt bucket elevator consists of conveying device with fixed buckets driving and loading devices,loading and unloading boots with branch pipes and a casing .The reliable gear motor drives the vertical belt bucket elevator.The execution of elevator can be left installed or right-installed drive (installation from the side of loading branch pipe ). The designs of elevator provides a brake or stop device to prevent the spontaneous backward running of working part.
The steel housing with loading and unloading branch pipe plays role as a supporting part and protection against environmental attack on material .
The bulk material is loaded the bottom of the elevator ( loading boot end ) through loading branch and enters the buckets then ,it goes vertically and enters the tank or silo or hopper throughout unloading elevator branch throughout loading branch installed on the top ( unloading boot end ) due to centrifugal force created by drive pulley.The empty overturned buckets return to the low section ,after that the cycle repeats .
Transported material bulk density
Main motor power
3 kw, with back stop device
Auxiliary motor power
Belt material and Color
(1) Simplicity and structural reliability
(2) Access hatch
(3) Lining of the bottom of loading boot that provides the friction decrease and power costs accordingly
(4) Application of reliable components of well known manufacturers :
--Motor : SEW,ABB,SIEMENS,NORD
--Bearing : SKF,NSK,NIN,FAG
(5) Competitive price
How to send us a correct inquiry
(2)Distance between inlet and outlet
(3)Transport capacity= ?T/H
(4)Bulk density of transported materials = ? kg/m3
(5)Work continuous or not
(6)Voltage at your location .in China, it is 380V,50HZ,3PH
(7)Which seaport is near to you
(8)Motor & gearbox ,bearing’s brand .
(9)Quantity ,MOQ is 1 set
(10)Stainless steel or carbon steel
(11)Surface treatment on conveyors :
For stainless steel ,there are three ways :
acid clean; B.sand blasting; C.Polished from Ra 0.1um to 3.2um
For carbon steel ,there are one way : only painting .Painting color is as per request .
Assemble before delivery
We will make test run video without material after assembling and before delivery .
We also invite customers to make inspection at Changrong workshop .
(1)Q: Are you trading company or manufacturer ?
A: We are a manufacturer with our own factory.
(2)Q: What is size of your factory?
(3)Q: How many employees at your factory ?
A: 70 .including 8 engineers
(4)Q: What are certification do you have ?
(5)Q：Can I make our own logo on package?
(6)Q:What is your service?
A: Provide free design + free consult + excellent manufacturing + reliable warranty period + reach job site for solving problems if necessary
(7)Q: What is payment?
A: It can be negotiated .Usually we take T/T or L/C at sight .
(8)Q:Can I visit Wuxi Changrong factory?
A:Certainly .Wuxi Changrong locates in Wuxi , one hour by high speed train from Shanghai . We welcome customers from all over world to visit our factory. Just give us a call ,then we tell you the specific traffic way . Just call us now.
Please feel free to send us your detailed requirements, you would be satisfied with our service.
WUXI CHANGRONG CONVEYING MACHINERY CO., LTD.
Add：Jiang Industrial Zone, Qianzhou Town, Huishan District,
Wuxi Jiangsu Province
If you're looking for grain bucket elevators equipments, CHANGRONG CONVEYING MACHINERY must be your best choice. We will offer you good service and fast delivery.
