Small Screw Conveyor Auger Screw Feeder

Small Screw Conveyor introduction Wuxi Changrong’s Small Screw Conveyor is designed to transport bulk powder materials between two points (feeding point and discharging point ) .Its advantage is to work with load cell ,so as to get a correct accuracy feeding rate for silos and other mixers...

Description

Small Screw Conveyor introduction

Wuxi Changrong’s Small Screw Conveyor is designed to transport bulk powder materials between two points (feeding point and discharging point ) .Its advantage is to work with load cell ,so as to get a correct accuracy feeding rate for silos and other mixers .Usually it is fed bulk powder materials to the hoppers,silos,tanks,mixers and other conveying equipment.Its outline shape can be pipe shape or U shape .It can transport bulk powder materials,small granules and other fine materials  horizontally or vertically as per request .Meanwhile ,it can be moved here and there with mobile wheels on support legs .The length and size of small screw conveyor will be made as per transported material’s feature .Usually ,1 set of small screw conveyor’s length is less than 10 meters .





Technical Data

Diameter

100 mm

160 mm

200 mm

250 mm

Speed

16 rpm

32 rpm

131 rpm

90 rpm

Motor Power

2.2 KW

1.1kw

5.5 kw

4 kw

Capacity

0.5M3/H

1-2 M3/H

3.5 M3/H

15 M3/H

Transport Length

1610 mm

1700 mm

5850 mm

5200 mm

Transport Direction

Horizontal

Horizontal

Incline ;

Incline degree is 35-490

Incline ;

Incline degree is 300



Outstanding Details on Screw Conveyors



Operation Process

(1)Small screw conveyor is made up of gearbox with motor, drive and driven sprocket, chain, screw flight, casing, frame, etc.

(2) Its working principle is : The bulk material feed into the casing and screw flight was hold back by the frication resistance acted on the wall of casing during running, the screw flight push the material and make the material do axial movement.

(3)Meanwhile ,  the clockwise and counterclockwise screw fight act as mixer.

(4)The material can be discharged at the proper outlet at the bottom of casing or transport out at the end of chute.





Advantage

(1) conveyor with simple construction

(2) be able to feed and discharge in many positions

(3) it is easy to operate, have good seal capability

(4) Environmental equipment


How to send us an inquiry

(1) transport length

(2) Transport direction : horizontal, incline or vertical

(3) Transport capacity= ?T/H

(5) Bulk density of transported materials = ? kg/m3

(6) Work continuous or not

(4) Voltage at your location .in China, it is 380V,50HZ,3PH

(5) Which seaport is near to you

(6) Quantity ,MOQ is 1 set

(7) Stainless steel or carbon steel

(8) Surface treatment on conveyors :

(9) For stainless steel ,there are three ways :

(10) acid clean; B. sand blasting; C. Polished from Ra 0.1um to 3.2um

(11) For carbon steel ,there are one way : only painting .Painting color is as per request .


FAQ

(1)Q: Are you trading company or manufacturer ?

A: We are a manufacturer with our own factory.

(2)Q: What is size of your factory

A: 10,000M2

(3)Q: How many employees at your factory ?

A: 70 .including 8 engineers

(4)Q: What are certification do you have ?

A: CE,ISO9001-2008

(5)Q:Can I make our own logo on package?

A:Yes.







Please feel free to send us your detailed requirements, you would be satisfied with our service.
